Name: Atomos Shinobi 7 RX HDR Monitor
Brand: ATOMOS
SKU: 6065805
Price: 651 EUR
Availability: InStock

Top-Features

7" HDR display with 2200 nits peak brightness - clearly visible even in sunlight
Supports 4Kp60 via HDMI and HDp60 via
via 3G-SDI
Camera control via USB-C for Canon, Fujifilm, Nikon, Panasonic, Sony + Z CAM (optional)
Wi-Fi 6E for TX-RX systems from Atomos or RTSP H.264
Streaming
Versatile monitoring tools:
Waveform, Vectorscope, Histogram, RGB Parade
3D LUTs (.cube, 17/33 points) + HDR modes (HLG/PQ)
Anamorphic Desqueeze & Frame Guides (cinema + social media)
Compact design with passive cooling
Flexible power supply: NP-F battery, USB-C PD, DC-In (optional)

Show all technical data

Details

Atomos Shinobi 7 RX HDR Monitor

The Atomos Shinobi 7 RX offers an impressive 7-inch HDR display with a peak brightness of 2200 nits, guaranteeing crystal clear viewing even in direct sunlight. With support for 4Kp60 via HDMI and HDp60 via 3G-SDI, the monitor is perfect for professional film and video productions

. USB-C allows you to control cameras from Canon, Fujifilm, Nikon, Panasonic, Sony and optional Z CAM. Thanks to Wi-Fi 6E, TX-RX systems from Atomos or RTSP H.264 streams can be easily integrated.

The Shinobi 7 RX offers a variety of monitoring tools, including Waveform, Vectorscope, Histogram and RGB Parade, as well as 3D LUTs (.cube, 17/33 points) and HDR modes (HLG/PQ), so that you can optimally assess your recordings. Additional functions such as Anamorphic Desqueeze and flexible frame guides for cinema or social media formats round off the package.

Despite the extensive functions, the monitor remains compact and lightweight (198 × 133 × 39 mm, 580 g) and operates silently thanks to passive cooling. Power is supplied flexibly via NP-F battery, USB-C PD or optional DC-In - perfect for mobile use.

Specs

General
Type	7-inch HDR monitor with 2200 nits and camera control
Colour	black

Features
Material	ABS polycarbonate

Image sensor
Resolution	1920 × 1080 Pixel

Display
Screen size (in inches)	7 "

Power Supply
battery type	NP-F battery

Dimensions
Dimensions	198 x 133 x 39 mm
Weight (incl. battery and memory card)	580 g

Other features
Functions	Cooling type: Passive heat sink, Backlight: Edge-lit, Brightness (cd/m² / Nits): 2200, Calibration support: Calibrite Display Pro / Display Plus (PC/Mac) via Atomos LANC cable
Interesting	Mounting points: 1 × anti-rotation thread 1/4 inch / 3/8 inch (top & bottom)
Connectivity	WLAN,USB Type C,HDMI
other functions	Input voltage: 6.2 V - 16.8 V, operating voltage: 5.8 V - 7.2 V, multifunction button: on/off / lock screen
